DOOR OPEN TOO LONG (DOTL) ZONES
This selects the zones that will generate a DOTL alert if the zone is unsealed for longer
than the time set by P304E.
The types of alerts are set by P121E 7E, P122E 7E and P305E.
PROGRAMMING SEQUENCE:
P303E 1E–16E toggles the options ON and OFF
OFF: DOTL is disabled for that zone
ON: DOTL is enabled for that zone
P303E
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
All OFF: No DOTL zones.
NOTES
Zones can be assigned as DOTL zones in
addition to normal alarm functions. Therefore,
DOTL zones can operate as alarm zones when
armed and DOTL zones when disarmed. (Day
Zone programming still applies).
ZONES 1–8 (D8 & D16) ZONES 916 (D16)
Option No. Description
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
P303E DOTL ZONES
DOTL TIME
Sets the delay time in seconds before a DOTL zone generates a DOTL alert. Enter a
value between 01 and 99.
PROGRAMMING SEQUENCE:
P304E existing DOTL time is displayed one digit at a time
[ENTER NEW VALUE] E new value is displayed one digit at a time
P304E
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
20 seconds.
Option No. Description Default Note
P304E DOTL TIME 20 0199 seconds
PROGRAMMING SEQUENCE:
P305E [1E–8E] toggles the options ON and OFF
DOTL OUTPUT LATCHES
With this option on, DOTL alerts will either follow the sealed/unsealed state of DOTL
zones or latch the Aux output/s which have been programmed for DOTL alerts.
1E OFF: DOTL Outputs follow the state of DOTL zones set by P303E. (Factory default).
1E ON: DOTL Outputs latch on until reset by disarming the panel.
DOTL ALERTS TO OUTPUT EXPANDER
With this option on, DOTL alerts will be sent to the optional Output Expander on the
same output number as the DOTL zone number. P305E 1E settings apply.
2E OFF: No DOTL Alerts to the Output Expander. (Factory default).
2E ON: DOTL Alerts sent to the Output Expander.
DOTL ALERTS TO KEYPAD
With this option on, DOTL alerts will SLOWLY Flash the corresponding zone light on the
keypad. P305E 1E settings apply.
5E OFF: No DOTL Alerts to the Keypad. (Factory default).
5E ON: DOTL Alerts slow flash zone lights on the Keypad..
P305E 1E
RELATED OPTIONS
P121E 7E DOTL Alerts to Aux1.
P122E 7E DOTL Alerts to Aux2.
P305E 2E
RELATED OPTIONS
P117E 1E Enable Output Expander.
P305E 5E
PROGRAM MODE LEVEL
Installer mode or NessComms.
STROBE FLASH ON ARM/DISARM BY READER
This option enables strobe flash when arming and disarming by Reader. (D8x/D16x
versions prior to V5.4 had strobe flash permanently enabled).
PROGRAMMING SEQUENCE:
P301E 8E toggles the option ON and OFF
OFF: Strobe flash disabled ON: Strobe flash enabled
P301E 8E
THIS OPTION IS AVAILABLE IN
D8X/D16X V5.3 AND LATER
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
ON
Option No. Description Default
P305E
1E DOTL output LATCHES
OFF
2E DOTL outputs to Output Expander
OFF
3E
[not used] OFF
4E
[not used] OFF
5E DOTL zone flashes on keypad
OFF
6E
[not used] OFF
7E
[not used] OFF
8E
[not used] OFF
76
ACCESS CONTROL
Ness D8x / D16x Control Panel – Installation Manual
