Ness D8X Installation & Programming Manual

PROGRAMMING SEQUENCE:
P338E [1E–4E] toggles the options ON and OFF.
READERS 1–3 to AUX OUTPUTS 1–4
These options give the flexiblity of assigning any access reader to any Aux output
for operating door strikes, magnetic locks, etc. Readers can be assigned to multiple
outputs. Always use an external relay board (100-719) on each Aux output if
connecting devices which draw more than 100mA.
P318E [1E–4E] Toggles the options.
1E ON: Reader 1 output to Aux1 (P121E 8E must also be on).
2E ON: Reader 1 output to Aux2 (P122E 8E must also be on).
3E ON: Reader 1 output to Aux3 (P123E 8E must also be on).
4E ON: Reader 1 output to Aux4 (P124E 8E must also be on).
P328E [1E–4E] Toggles the options.
1E ON: Reader 2 output to Aux1 (P121E 8E must also be on).
2E ON: Reader 2 output to Aux2 (P122E 8E must also be on).
3E ON: Reader 2 output to Aux3 (P123E 8E must also be on).
4E ON: Reader 2 output to Aux4 (P124E 8E must also be on).
P338E [1E–4E] Toggles the options.
1E ON: Reader 3 output to Aux1 (P121E 8E must also be on).
2E ON: Reader 3 output to Aux2 (P122E 8E must also be on).
3E ON: Reader 3 output to Aux3 (P123E 8E must also be on).
4E ON: Reader 3 output to Aux4 (P124E 8E must also be on).
P318E 1E–4E
RELATED OPTIONS
P121E 8E, P122E 8E, P123E 8E,
P124E 8E, P319E, P329E, P339E.
P328E 1E–4E
RELATED OPTIONS
P121E 8E, P122E 8E, P123E 8E,
P124E 8E, P319E, P329E, P339E.
P338E 1E–4E
RELATED OPTIONS
P121E 8E, P122E 8E, P123E 8E,
P124E 8E, P319E, P329E, P339E.
PROGRAM MODE LEVEL
Installer mode or NessComms.
P319E, P329E, P339E
PROGRAM MODE LEVEL
Installer mode or NessComms.
RELATED OPTIONS
P318E, P328E, P338E.
READERS 1–3 OUTPUT TIME
This sets the time that the outputs selected by P318E, P328E and P338E are ON.
Range 1-24 seconds.
PROGRAMMING SEQUENCE:
P319E, P329E or P339E existing Reader Output Time is displayed one digit at a time
[ENTER NEW VALUE] E new value is displayed one digit at a time
Option No. Description Default
P318E
1E Ultraprox Reader1 to AUX1
OFF
2E Ultraprox Reader1 to AUX2
OFF
3E Ultraprox Reader1 to AUX3
OFF
4E Ultraprox Reader1 to AUX4
OFF
P319E Ultraprox Reader1 output TIME
5 sec
P328E
1E Ultraprox Reader2 to AUX1
OFF
2E Ultraprox Reader2 to AUX2
OFF
3E Ultraprox Reader2 to AUX3
OFF
4E Ultraprox Reader2 to AUX4
OFF
P329E Ultraprox Reader2 output TIME
5 sec
P338E
1E Ultraprox Reader3 to AUX1
OFF
2E Ultraprox Reader3 to AUX2
OFF
3E Ultraprox Reader3 to AUX3
OFF
4E Ultraprox Reader3 to AUX4
OFF
P339E Ultraprox Reader3 output TIME
5 sec
77
ACCESS CONTROL
Ness D8x / D16x Control Panel – Installation Manual
