VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP – NF18ACV
UG01040 v 1.04 December 2018
The second group displays details of the current status of your WAN connection.
Line Rate – Upstream (Kbps)
The current synchronisation upstream speed of the
DSL connection in Kbps (Kilobits per second).
Line Rate – Downstream (Kbps)
The current synchronisation upstream speed of the
DSL connection in Kbps (Kilobits per second).
The current IPv4 LAN IP address assigned to the
router.
Displays whether the WAN connection is
ADSL/VDSL or Ethernet WAN.
The current default gateway address of the WAN
interface.
The current primary DNS server in use
The current secondary DNS server is use.
The current IPv6 LAN IP address in use if assigned.
The current IPv6 default gateway if assigned.
The current local date and time set on the router.
WAN
Further down on the page the WAN table shows more detailed information related to the WAN
interface configuration, including the firewall status, IPv4 and IPv6 addresses of the router.
The Interface of the WAN connection.
The description of the WAN connection.
The type of WAN connection.
Details the status of VLAN Mux ID, if used.
Details the status of IGMP on each WAN connection.
IGMP is only used with IP v4 connections.
IGMP proxy enables the router to issue IGMP host messages on behalf of hosts
that the router discovered through standard IGMP interfaces, allowing NAT
transversal of Multicast traffic.
Details the status of IGMP Src on each WAN connection.
IGMP Sources function send a membership report that includes a list of IGMP
source addresses.
Shows the status of the Multicast Listener Discovery protocol when IPv6 is in use.
Multicast Listener Discovery (MLD) proxy enables the router to issue MLD host
messages on behalf of hosts that the router discovered through standard MLD
interfaces.
