Chapter 2: Configuring System Information | 67
FS728TP Smart Switch Software Administration Manual
Field Description
Port Details
Local Port Displays the interface on the local system that received LLDP information
from a remote system.
MSAP Entry Displays the Media Service Access Point (MSAP) entry number for the
remote device.
Basic Details
Chassis ID Subtype Identifies the type of data displayed in the Chassis ID field on the remote
system.
Chassis ID Identifies the remote 802 LAN device's chassis.
Port ID Subtype Identifies the type of data displayed in the remote system’s Port ID field.
Port ID Identifies the physical address of the port on the remote system from which
the data was sent.
Port Description Identifies the user-defined description of the port.
System Name Identifies the system name associated with the remote device.
System Description Specifies the description of the selected port associated with the remote
system.
System Capabilities Specifies the system capabilities of the remote system.
Managed Addresses
Address SubType Specifies the type of the management address.
Address Specifies the advertised management address of the remote system.
Interface SubType Specifies the port subtype.
Interface Number Identifies the port on the remote device that sent the information.
MAC/PHY Details
Auto-Negotiation Supported Specifies whether the remote device supports port-speed auto-negotiation.
The possible values are True or False
Auto-Negotiation Enabled Displays the port speed auto-negotiation support status. The possible values
are True or False
Auto Negotiation Advertised
Capabilities
Displays the port speed auto-negotiation capabilities.
Operational MAU Type Displays the Medium Attachment Unit (MAU) type. The MAU performs
physical layer functions, including digital data conversion from the Ethernet
interface collision detection and bit injection into the network.
