Table 1. Power button usage
ActionDesired Result
Press and hold the Power button for three seconds.Turn on the mobile router.
Press and hold the Power button for five seconds.Turn off the mobile router.
Press and quickly release the Power button.Wake the mobile router.
Mobile Router Connectors
The following figure shows a rear view of the mobile router with the ports and connectors.
USB Type-C connector
RJ-45 ethernet port
TS-9 external antenna
connector
TS-9 external antenna
connector
Figure 2. Mobile router connectors
The mobile router has the following ports and connectors:
•
USB type-C connector. Connect the USB type-C cable that came in the package to
recharge the battery or for a tethered connection to a computer.
For more information about recharging the battery, see Recharge the Battery From
a Wall Socket on page 24 and Recharge the Battery From a Computer USB Port on
page 25.
A tethered connection to a computer lets you access the mobile router from a web
browser without a WiFi connection. See Tethered Connection on page 18.
•
LAN/WAN port. You can connect an Ethernet-compatible device to this port. Devices
connected to the mobile router over WiFi and devices connected to this port can
send and receive information to each other.
When you are using an Ethernet connection, you can use the USB Type-C cable and
the AC adapter to recharge the mobile router battery.
User Manual10Get Started
Nighthawk M5 5G WiFi 6 Mobile Router
