Hardware Setup
10
R6300v2 Smart WiFi Router
on. If this LED is off, the wireless radios are turned off and you cannot connect wirelessly
to the router.
WPS button.
You can use this button to use WPS to add a wireless device or computer
to your wireless network. The Wireless LED blinks blue when the router is trying to add
the wireless device or computer. The LED stays solid blue when wireless security is
enabled in the router.
Rear Panel
The rear panel has the connections and buttons shown in the following figure.
USB 3.0 Ethernet Internet
Power On/Off
Power connector
port
LAN ports 1–4
Reset
buttonport
Figure 3. Router rear panel
The Reset button restores the factory settings. See Factory Settings on page 132.
Label
The label on the bottom of the router shows the login information, MAC address, and serial
number.
Serial number andPreset WiFi
Default access information
password MAC address
Figure 4. The label shows unique information about your router
