Advanced Settings
112
R6300v2 Smart WiFi Router
length of the prefix, which is also indicated by the underline (_) under the IPv6
address. If no address is acquired, the field displays Not Available.
• Router
’s IPv6 Address on LAN. This field shows the IPv6 address that is acquired
for the router’s LAN interface. The number after the slash (/) is the length of the prefix,
which is also indicated by the underline (_) under the IPv6 address. If no address is
acquired, the field displays Not Available.
3. Specify how the router assigns IPv6 addresses to the devices on your home network (the
LAN) by selecting one of the following radio buttons:
• Use DHCP Server.
This method passes more information to LAN devices, but some
IPv6 systems might not support the DHCv6 client function.
• Auto Config.
This is the default setting.
4. (Optional) Select the Use This Interface ID check box, and specify the interface ID that you
want to be used for the IPv6 address of the router
’s LAN interface.
If you do not specify an ID here, the router generates one automatically from its MAC
address.
5. Click the Apply button.
IPv6 Auto Config
To set up an IPv6 Internet connection through auto configuration:
1. Select ADV
ANCED > Advanced Setup > IPv6.
The IPv6 screen displays.
2. In the Internet Connection
Type list, select Auto Config.
The screen adjusts:
The router automatically detects the information in the following fields:
• Router
’s IPv6 Address on WAN. This field shows the IPv6 address that is acquired
for the router’s WAN (or Internet) interface. The number after the slash (/) is the
To Next Page
