NETGEAR R6300v2 User Manual

NETGEAR genie ADVANCED Home
35
R6300v2 Smart WiFi Router
 To change the MTU size:
1. Select ADVANCED > Setup > WAN Setup.
2. In the MTU Size field, enter a value from 64 to 1500.
3. Click the Apply button.
Your change is saved.
LAN Setup
The LAN Setup screen allows configuration of LAN IP services such as Dynamic Host
Configuration Protocol (DHCP) and Routing Information Protocol (RIP).
The router is shipped preconfigured to use private IP addresses on the LAN side and to act
as a DHCP server. The router’s default LAN IP configuration is:
• LAN IP address. 192.168.1.1
• Subnet mask. 255.255.255.0
These addresses are part of the designated private address range for use in private networks
and are suitable for most applications. If your network requires a different IP addressing
scheme, you can change these settings in the LAN Setup screen.
Note: If you change the LAN IP address of the router while connected
through the browser, you are disconnected. If you want to continue to
use the router menus, open a new connection to the new IP address
and log in again.
1472 Maximum size to use for pinging. (Larger packets are fragmented.)
1468 Used in some DHCP environments.
1460 Usable by AOL if you do not have large email attachments, for example.
1436 Used in PPTP environments or with VPN.
1400 Maximum size for AOL DSL.
576 Typical value to connect to dial-up ISPs.
Table 2. Common MTU sizes (continued)
MTU Application

NETGEAR R6300v2 Specifications

General

WiFi Technology	802.11ac Dual Band Gigabit
WiFi Range	Medium to large homes
USB Ports	1 x USB 3.0, 1 x USB 2.0
Wireless Standard	802.11a/b/g/n/ac
Frequency Band	2.4 GHz and 5 GHz
Processor	800 MHz
Ethernet Ports	4 x Gigabit LAN, 1 x Gigabit WAN
Antenna	3 external antennas
Security	WPA/WPA2-PSK
Ports	1x WAN, 4x LAN, 1x USB 3.0, 1x USB 2.0
Memory	256 MB RAM, 128 MB Flash
WiFi Speed	Up to 1750 Mbps (450 Mbps on 2.4 GHz + 1300 Mbps on 5 GHz)
