NETGEAR R6300v2 User Manual

Advanced Settings
100
R6300v2 Smart WiFi Router
 To set up the router as an AP:
1. Connect an Ethernet cable to the Internet port of this router and to a LAN port in the
other router
.
Cable this port to a LAN port
on the other router
2. Select ADVANCED > Wireless AP.
3. Select the Enable Access Point Mode check box.
The screen adjusts.
4. (Optional) If you want to manually assign a specific IP address to this router while it is in
AP
mode, select the enable fixed IP setting on this device (not recommended) check box.
5. Click the Apply button.
The IP address of the router changes, and you are disconnected. To reconnect, close
and restart your web browser
, and type http://www.routerlogin.net.

NETGEAR R6300v2 Specifications

General

WiFi Technology	802.11ac Dual Band Gigabit
WiFi Range	Medium to large homes
USB Ports	1 x USB 3.0, 1 x USB 2.0
Wireless Standard	802.11a/b/g/n/ac
Frequency Band	2.4 GHz and 5 GHz
Processor	800 MHz
Ethernet Ports	4 x Gigabit LAN, 1 x Gigabit WAN
Antenna	3 external antennas
Security	WPA/WPA2-PSK
Ports	1x WAN, 4x LAN, 1x USB 3.0, 1x USB 2.0
Memory	256 MB RAM, 128 MB Flash
WiFi Speed	Up to 1750 Mbps (450 Mbps on 2.4 GHz + 1300 Mbps on 5 GHz)
