NETGEAR WAC510 User Manual

Manage the advanced radio features
You can manage the advanced radio features that are described in the following sections:
• Manage the advanced WiFi settings for the radios
• Manage the maximum number of clients for a radio
• Manage the broadcast and multicast settings for a radio
• Manage load balancing for the radios
For information about the basic radio features, see Manage the basic radio features on
page 76.
Manage the advanced WiFi settings for the radios
The advanced WiFi settings for the radios apply to all WiFi networks (VAPs or SSIDs).
You can specify the radio settings for the 2.4 GHz and 5 GHz radios individually. For
information about the basic radio settings, see Manage the basic settings for the radios
on page 76.
A radio must be turned on for you to specify the settings. For more information about
turning a radio on, see Turn a radio on or off on page 80.
To manage the advanced WiFi settings for the radios:
1.
Open a web browser from a computer that is connected to the same network as the
access point or directly to the access point through an Ethernet cable or WiFi
connection.
2. Enter the IP address that is assigned to the access point.
A login window opens.
If your browser does not open the login window but displays a security message
and does not let you proceed, see Log in to the access point after initial setup on
page 41.
3. Enter the access point user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
If you previously added the access point to a NETGEAR Insight network location and
managed the access point through the Insight app or Insight Cloud portal, enter the
Insight network password for that location. For more information, see Connect over
WiFi using the NETGEAR Insight App on an iOS or Android mobile device on page
26).
The Dashboard page displays.
User Manual91Manage the Advanced WiFi and
Radio Features
Insight Managed Smart Cloud Wireless Access Point WAC510 User Manual

NETGEAR WAC510 Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11ac, IEEE 802.11i, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	400 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Internal	No
Placement	Ceiling, Wall
Product color	White
LED indicators	Link, Network, Power
Antenna gain level (max)	6 dBi
Security algorithms	WPA, WPA2
Service Set Identifier (SSID) features	SSID broadcast on/off
Input current	2.5 A
AC input voltage	12 V
Power consumption (typical)	9.3 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	197.32 mm
Height	37 mm
Weight	555.5 g
