RangeMax Dual Band Wireless-N Modem Router DGND3300 User Manual
Customizing Your Network Settings 6-18
v1.0, January 2010
Select Static Routes under Advanced in the main menu. The Static Routes screen displays.
To add or edit a static route:
1. Click Add to open the Static Routes screen.
2. In the Route Name field, type a name for this static route. (This is for identification purposes
only.)
3. Select the Private check box if you want to limit access to the LAN only. If Private is selected,
the static route is not reported in RIP.
4. Select the Active check box to make this route effective.
5. Type the destination IP address of the final destination.
6. Type the IP subnet mask for this destination.
If the destination is a single host, type 255.255.255.255.
7. Type the gateway IP address, which must be a router on the same LAN segment as the Dual
Band Wireless-N Modem Router.
8. Type a number between 1 and 15 as the metric value.
This represents the number of routers between your network and the destination. Usually, a
setting of 2 or 3 works, but if this is a direct connection, set it to 1.
9. Click Apply to have the static route entered into the table.
Figure 6-10
Figure 6-11
