NETGEAR Wireless-N User Manual

RangeMax Dual Band Wireless-N Modem Router DGND3300 User Manual
Protecting Your Network 3-12
v1.0, January 2010
Adding a Custom Port Forwarding Rule
1. From the Port Forwarding screen, click Add.
2. Select the Custom Rule radio button and the screen changes:
3. Enter a name in the Service Name field.
4. In the Service Type field, select the protocol. If you are unsure, select TCP/UDP.
5. Fill in the Starting Port and Ending Port fields.
6. In the Server IP Address field, enter the IP address of your local computer that will provide
this service.
7. Click Apply. The service appears in the list.
Figure 3-8

NETGEAR Wireless-N Specifications

General

Wireless Speed	Up to 300 Mbps
Frequency Band	2.4 GHz
VPN Support	No
Antennas	2 external antennas
Security	WPA, WPA2, WEP
Ethernet Ports	4 x 10/100 Mbps LAN ports, 1 x 10/100 Mbps WAN port
