RangeMax Dual Band Wireless-N Modem Router DGND3300 User Manual
Default Configuration and Technical Specifications B-4
v1.0, January 2010
Environmental
Operating temperature 0 to 40 C (32º to 104º F)
Operating humidity 10% to 90% relative humidity, noncondensing
Storage temperature -20 to 70 C (-4º to 158º F)
Regulatory Compliance
Meets requirements of FCC Part 15 Class B; VCCI Class B; EN 55 022 (CISPR 22), Class B
Interface Specifications
LAN 10BASE-T or 100BASE-Tx, RJ-45
WAN (ADSL) ITU 992.1 (G.dmt) Annex A, ITU 992.2 (G.lite), ITU 992.3 ADSL2
(G.dmt.bis), ITU 992.5 ADSL2+. Annex A ADSL is supported by
DGND3300, Annex B ADSL is supported by DGND3300.
USB
File systems FAT, FAT32, NTFS (read only) and Linux
Table B-1. Specifications (continued)
