NETGEAR Wireless-N User Manual

RangeMax Dual Band Wireless-N Modem Router DGND3300 User Manual
Protecting Your Network 3-8
v1.0, January 2010
To add or edit a rule from the Firewall Rules screen:
1. To edit a rule, select its radio button. To add a rule, click Add (it does not matter which radio
button is selected).
Depending on your selection, either the Outbound Services screen or Inbound Services screen
is displayed.
2. Select the service that you want to add or edit.
3. Enter the settings to specify the service (see Table 3-1 on page 3-9).
4. Click Apply to have your changes take effect.
The new rule will be listed in the table when you return to the Firewall Rules screen.
Figure 3-5

NETGEAR Wireless-N Specifications

General

Wireless Speed	Up to 300 Mbps
Frequency Band	2.4 GHz
VPN Support	No
Antennas	2 external antennas
Security	WPA, WPA2, WEP
Ethernet Ports	4 x 10/100 Mbps LAN ports, 1 x 10/100 Mbps WAN port
