Basic Installation and Configuration
38
ProSAFE Dual Band Wireless N Access Point WNDAP350
Configuring the RADIUS Server Settings
You can setup or modify the RADIUS Server settings to compliment Network Authentication
security options. The RADIUS Server must be used with Legacy 802.1x, and can be used
with WPA and WPA2 Network Authentication. When using a RADIUS Server, the RADIUS
Server settings must be configured before completing the Network Authentication security
profile (see Configuring WPA with RADIUS on page 42, Configuring WPA2 with RADIUS on
page 43, or Configuring WPA and WPA2 with RADIUS on page 44 for specifics on
implementing these security options).
Note: The RADIUS Server Settings apply to all profiles. They only need to
be configured once per wireless access point.
To set up or modify the RADIUS Server Settings:
1. From your Web browser, log in to the WNDAP350 using the default LAN address of
http://192.168.1.1, user name admin and password password, or use the LAN address
and password that you set up.
2. Under the Configuration tab, select Security on the main menu, select Advanced from the
left panel, and then select RADIUS Server Settings. The RADIUS Server Settings screen
displays, as shown in Figure 16, RADIUS server settings.
Figure 16. RADIUS server settings
3. Enter the following RADIUS Server settings:
• Authentication Server. This configuration is required for authentication using a
RADIUS Server. The IP Address, Port Number, and Shared Secret are required for
communication with the Primary RADIUS Server. You can also configure a
Secondary RADIUS Server to use, if the Primary RADIUS Server fails.
- IP Address. The IP address of the RADIUS Server.
