Advanced Configuration
78
ProSAFE Dual Band Wireless N Access Point WNDAP350
• Configure the WNDAP350 (AP3) on LAN 3 in Point-to-Point Bridge mode with the
Remote MAC Address of AP2.
3. Verify the following parameters for all access points:
• Verify that the LAN network configuration the WNDAP350 wireless access points are
configured to operate in the same LAN network address range as the LAN devices
• Only one access point is configured in Point-to-Multi-Point Bridge mode, and all the
others are in Point-to-Point Bridge mode.
• All access points must be on the same LAN. That is, all the APs LAN IP address must
be in the same network.
• If using DHCP, all WNDAP350 wireless access points should be set to Obtain an IP
address automatically (DHCP Client) in the IP Address Source portion of the Basic IP
Settings menu.
• All WNDAP350 wireless access points use the same SSID, Channel, authentication
mode, if any, and encryption in use.
• All Point-to-Point Access Points must have the AP2 MAC address in its Remote AP
MAC address field.
4. Verify connectivity across the LANs.
• A computer on any LAN segment should be able to connect to the Internet or share
files and printers with any other PCs or servers connected to any of the three LAN
segments.
• Wireless stations will be able to connect to the WNDAP350 wireless access points in
the illustration above. If you require wireless stations to access any LAN segment,
you can add additional WNDAP350 wireless access points configured in Wireless
Access Point mode to any LAN segment.
5. Click Apply to save your settings.
Note: You can extend this multi-point bridging by adding additional
WNDAP350s configured in Point-to-Point mode for each additional
LAN segment. Furthermore, you can extend the range of the wireless
network with NETGEAR wireless antenna accessories.
