XS728T ProSAFE 28-Port 10-Gigabit L2+ Smart Switch
The following table describes the fields on this page: .
4. In the Binding Configuration area, the Inbound only packet filtering direction for an ACL is
selected in the Direction field.
5. In the Port Selection Table area, displays the list of all available, valid interfaces for ACL
mapping.
All physical interfaces and interfaces participating in the LAG are listed.
To apply the ACL to a selected interface, check the boxes beneath the required interfaces
and then click Add. Update the switch with the new settings. Configuration changes take
effect immediately.
ACL Based on Fields
Destination MAC • Destination MAC. Specify the destination MAC address to compare against an
ethernet frame. The valid format is (xx:xx:xx:xx:xx:xx). The BPDU keyword
might be specified using a destination MAC address of 01:80:C2:xx:xx:xx.
• Destination MAC Mask. specify the destination MAC address mask specifying
which bits in the destination MAC to compare against an ethernet frame. The
valid format is (xx:xx:xx:xx:xx:xx). The BPDU keyword might be specified using
a destination MAC mask of 00:00:00:ff:ff:ff.
Source MAC • Source MAC. Specify the source MAC address to compare against an ethernet
frame. The valid format is (xx:xx:xx:xx:xx:xx).
• Source MAC Mask. Specify the source MAC address mask specifying which
bits in the source MAC to compare against an ethernet frame. Valid format is
(xx:xx:xx:xx:xx:xx).
Destination IPv4 • Destination IP Address. Specify the destination IP address.
• Destination IP Mask. Specify the destination IP address mask.
Source IPv4 • Source IP Address. Specify the source IP address.
• Source IP Mask. Specify the source IP address mask.
Destination IPv6 • Destination Prefix. Specify the destination prefix.
• Destination Prefix Length. Specify the destination prefix length.
Source IPv6 • Source Prefix. Specify the source destination prefix.
• Source Prefix Length. Specify the source prefix length.
Destination IPv4 L4
Port
• Destination L4 port (protocol). Specify the destination IPv4 L4 port protocol.
• Destination L4 port (value). Specify the destination IPv4 L4 port value.
Source IPv4 L4 Port • Source L4 port (protocol). Specify the source IPv4 L4 port protocol.
• Source L4 port (value). Specify the source IPv4 L4 port value.
Destination IPv6 L4
Port
• Destination L4 port (protocol). Specify the destination IPv6 L4 port protocol.
• Destination L4 port (value). Specify the destination IPv6 L4 port value.
Source IPv6 L4 Port • Source L4 port (protocol). Specify the source IPv6 L4 port protocol.
• Source L4 port (value). Specify the source IPv6 L4 port value.
