BA 6001/9001/10001 En – Edition 2.0 * 6001b530.fm 5-27
Maintenance
Wheel change
The wheels are heavy and can damage the threads on the wheel studs if they
are handled incorrectly!
☞ Use suitable assembly tools, such as covering sleeves for the studs, a jack
etc.
Removing the wheels
Proceed as follows:
☞ Park the machine on level and firm ground and prevent it from rolling away
☞ Slightly loosen the wheel nuts of the wheel you want to remove
☞ Place a jack under the axle body, making sure it is standing firmly
☞ Raise the side of the axle from which you want to remove the wheel
☞ Check the machine is standing firmly
☞ Completely remove the wheel nuts
☞ Remove the wheel
Fitting the wheels
Proceed as follows:
☞ Place the wheel onto the wheel studs
☞ Tighten all wheel nuts part-way
☞ Lower the raised axle
☞ Tighten the wheel nuts to the prescribed torque of 350 – 300 Nm
Subsequent to changing wheels check the wheel nuts for tightness after
10
service hours – tighten if necessary!
