3-32 BA 6001/9001/10001 En – Edition 2.0 * * 6001b330.fm
Operation
3.17 Doors
Close the doors when driving.
Danger of accidents!
☞ Close the doors before moving the machine!
Opening the doors from the outside:
☞ Press door locks A
Locking the doors:
☞ Turn the key in door locks A to the left (L)
☞ The doors are locked
Unlocking the doors
☞ Turn the key in door locks A to the right (R)
☞ The doors are unlocked
Opening the doors from the inside
☞ Press the lever on the inside on door locks B down
Door arresters
Locking the doors in the arresters:
☞ Press doors C against brackets D of the arresters until they engage with an audible
click.
Releasing the door:
☞ Turn twist knob E to the right
➥ The doors are released
Fig. 31: Outside door openers and locks
R
L
A
Fig. 32: Inside left door opener
B
Fig. 33: Door arresters
C
D
E
