BA 6001/9001/10001 En – Edition 2.0 * 6001b510.fm 5-9
Maintenance
Filling up engine oil
Too much or incorrect engine oil can result in engine damage! For this reason:
☞ Do not add engine oil above the MAX mark of oil dipstick 18/A
☞ Use only the specified engine oil
Use a suitable container to collect the engine oil as it drains and dispose of it in an
environmentally friendly manner!
Filling up engine oil
☞ Proceed as follows:
• Clean the area around oil filler cap B with a lint-free cloth
• Open filler cap B
• Raise oil dipstick A slightly to allow any trapped air to escape
• Fill in engine oil
• Wait about 3 minutes until all the oil has run into the oil sump
• Check the oil level – see Checking the oil level on page 5-8
• Fill up if necessary and check the oil level again
• Close filler cap B
• Push oil dipstick A back in as far as possible
• Completely remove all oil spills from the engine
Fig. 19: Filling in engine oil (6001/9001/10001 with cab)
OIL
B
Fig. 19: Filling in engine oil (6001 Hydrostat)
OIL
B
