BA 6001/9001/10001 En – Edition 2.0 * 6001b330.fm 3-29
Operation
Working light
3.14 Cab heating and ventilation
The cab is fitted with five air nozzles. Each nozzle can be closed and directed
separately. In order to achieve best results for defrosting the front window, direct
the air nozzles to the front window.
• Open or close the nozzles as required to vent or heat the cab.
• Do not place flammable or explosive material or objects near the nozzles.
• Air the cab from time to time
Fig. 26: Working lights
13
Working light
ON
☞ Press switch 13 forwards to the 1st
position
➥ Front working light ON
ON
☞ Press switch 13 forwards to the 2nd
position
➥ Front and rear working lights
ON
OFF ☞ Press switch 13 fully backwards ➥ Lights switched OFF
Fig. 27: Air circulation in cab
18
Ventilation (fresh air)
1st
speed
☞ Press switch 18 forwards one step ➥ Low fan speed
2nd
speed
☞ Press switch 18 forwards two steps ➥ High fan speed
OFF ☞ Press switch 18 to the rear ➥ Fan OFF
