BA 6001/9001/10001 En – Edition 2.0 * 6001b610.fm 6-5
Specifications
6.13 Dimensions model 6001F (front skip)
Fig. 41: Machine dimensions (model 6001F)
Main data
Model 6001F
Dead weight
4120 kg (9083 lb)
Overall height
3080 mm (10’ 1’’)
Overall height with dumped-out skip
2550 mm (8’ 4’’
Overall height without rollbar
2300 mm (7’ 6’’
Overall width
2215 mm (7’ 3’’)
Ground clearance
380 mm (1’ 3’’)
Wheelbase
2485 mm (8’ 2’’)
Outside turning radius
5500 mm (18’ 1’’)
Hill climbing ability
50 % theoretically
Safe authorised inclination
25 % in all drive positions
