Neuson 6001 - Dimensions Model 9001

6-8 BA 6001/9001/10001 En – Edition 2.0 * * 6001b610.fm
Specifications
6.16 Dimensions model 9001
Fig. 44: Machine dimensions (model 9001)
Main data
Model 9001
Dead weight
4750 kg (10472 lb)
Overall height
3130 mm (10’ 3’’)
Overall height with dumped-out skip
2980 mm (9’ 9’’)
Overall height without rollbar
2320 mm (7’ 7’’)
Overall width
2420 mm (7’ 11’’)
Ground clearance
445 mm (1’ 6’’)
Wheelbase
2500 mm (8’ 2’’)
Outside turning radius
5500 mm (18’ 1’’)
Hill climbing ability
50 % theoretically
Safe authorised inclination
25 % in all drive positions
