3-28 BA 6001/9001/10001 En – Edition 2.0 * * 6001b330.fm
Operation
Multifunctional lever
The horn, the turn indicators and high beam are actuated with lever 21on the steering
wheel.
Interior light
Rotating beacon (option)
The rotating beacon (option) is switched on automatically as soon as ignition is switched
on.
Observe the legal regulations of your country for operating the rotating beacon.
H
V
Z
Fig. 23: Multifunctional lever
A
B
Light switch
Turn indicators
(left)
☞ Pull lever 21 backwards Z ➥ Left-hand side turn indicators
flash
Turn indicators
(right)
☞ Push lever 21 forwards V ➥ Right-hand side turn indicators
flash
Headlight flasher
☞ Pull lever 21 upwards A ➥ High beam is ON as long as
the lever is pulled
upwards
High beam (ON) ☞ Push lever 21 down B ➥ High beam (ON)
Horn
☞ Push lever 21 towards the
steering column E
➥ The horn sounds
Interior light
ON
☞ Press switch to the left or right
OFF
☞ Move switch to centre position
