Operation
Model 6001 Hydrostat with cab (option)
23
19
28
29
24
18
22
27
27
17
21
30
30
25
28
16
16
20
26
Pos.
Description
16 Seat
17 Steering wheel
18 Parking brake
19 Lever for horizontal seat adjustment
20 Forwards-reverse control
21 Turn indicator – horn – lights
22 Indicator
23 Skip control lever
24 Drinks holder (machines with cab)
25 Washer fluid tank (machines with cab)
26 Air vent (machines with cab)
27 Rearview mirror (option)
28 Handle
29 Storage compartment (machines with cab)
30 Door arresters
