Neuson 6001 - Brakes; Steering System; Work Hydraulics; Skip

6-2 BA 6001/9001/10001 En – Edition 2.0 * * 6001b610.fm
Specifications
6.4 Brakes
6.5 Steering system
6.6 Work hydraulics
6.7 Skip
6.8 Drive specifications
Service brake/parking brake
Models 6001/9001/10001
Design
Hydraulic pedal-operated wet dual-circuit brake
Location
Brake discs in either axle
Effect
Additional brake effect on rear axle via cardan shaft, parking brake effect on
front axle
Steering system
Models 6001/9001/10001
Design
Hydrostatic chassis articulation steering with emergency steering features
Steering mode
Chassis articulation steering
Work hydraulics
Model 6001 Models 9001/10001
Up to serial number AD From serial number AD
Hydraulic pump displacement
25 cm³/rev 22 cm³/rev 25 cm³/rev
Hydraulic pump flow rate
55 l/min (14.5 gpm) 57 l/min (15 gpm) 55 l/min (14.5 gpm)
Max. service pressure
220 bar (3191 psi) 220 bar (3191 psi) 220 bar (3191 psi)
Hydraulic tank capacity
70 l ( 18.5 gal) 70 l ( 18.5 gal) 70 l ( 18.5 gal)
Steering system
150 bar (2175.5 psi) 150 bar (2175.5 psi) 150 bar (2175.5 psi)
Skip
Model 6001F Model 6001S Model 9001 Model 10001
Skip capacity
2400 l struck
(634 gal)
3850 l struck
(107 gal)
4000 l struck
(1056.7 gal)
3200 l heaped
(845 gal)
4700 l heaped
(1241 gal)
4850 l heaped
(1281 gal)
1880 l liquid capacity
(496.6 gal)
2250 l liquid capacity
( 594.4 gal)
2250 l liquid capacity
( 594.4 gal)
Payload
6000 kg
(13227.7 lb)
9000 kg
(19841.6 lb)
10010 kg
(220484 lb)
Swivel angle
- 180 – 217° - -
Steering system
Model 6001 Hydrostat Models 6001/9001/10001
Drive speed I
0 – 5 kph 0 – 4.5 kph
Drive speed II
0 – 25 kph 0 – 7 kph
Drive speed III
- 0 – 14 kph
Drive speed IV
- 0 – 27 kph
Articulation
+/- 33° +/- 32.5°
Oscillation
+/- 15°
Outside turning radius
5200 mm (17’ 1’’) 6000 mm (19’ 8’’)
Hill climbing ability
50 % (theoretically)
25 % in all drive positions left/right
Safe authorised inclination
