3-34 BA 6001/9001/10001 En – Edition 2.0 * * 6001b330.fm
Operation
3.19 Front skip operation
Driving with a dumped-out skip is prohibited!
The working speed of the skip is set with the travel of the control lever and with
the accelerator pedal.
When dumping material into a pit, a firm resistance (beam) is required for
propping the front wheels!
☞ Never drive up to a pit only with the brakes!
Lowering the skip too rapidly and knocking it against the chassis can cause
damage and the dumper to tip over!
A
B
Fig. 34: Front skip operation
Position Lever Function
A
☞ Lever pushed forwards ➥ Dumping out the skip
B ☞ Lever pulled backwards ➥ Lower the skip
