BA 6001/9001/10001 En – Edition 2.0 * 6001b330.fm 3-25
Operation
3.11 Seat adjustment
Never change the seat position when driving or working – see Before starting
the engine on page 3-16
Danger of accidents!
☞ Adjust the seat before moving the machine
Weight adjustment
Adjust the seat suspension correctly to ensure a high level of ride comfort.
To adjust to a higher weight:
☞ Turn the adjusting wheel to the right.
To adjust to a lower weight:
☞ Turn the adjusting wheel to the left.
The specified weight is indicated by the yellow pointer next to the adjusting wheel.
Horizontal adjustment
☞ Sit down on the seat
☞ Pull lever 19 upwards and at the same time
☞ Move the seat forwards or backwards.
Backrest adjustment
☞ Pull lever R up and at the same time press against the backrest to move it to the
required position.
☞ Let lever R lock into place.
Fig. 17: Weight adjustment
70 kg
Fig. 18: Horizontal seat adjustment
19
Fig. 19: Backrest adjustment
R
