BA 6001/9001/10001 En – Edition 2.0 * 6001b320.fm 3-9
Operation
Pos.
Description
1 Telltale (red) – air filter
2 High beam telltale (blue)
3 Preheating telltale (yellow)
4 Telltale (red) – hydraulic oil filter
5 Converter oil temperature telltale (red)
6 Telltale (red) – alternator charge function
7 Parking brake telltale (red)
8 Telltale (red) – engine oil pressure
9 Telltale (red) – coolant temperature
10 Turn indicator telltale (green)
11 Fuel gauge
12 Hour meter
13 Working light switch
14 Low speed switch (turtle)
15 Ignition lock
16 Hazard warning switch
17 Wiper switch
18 Fan switch
19 Air conditioning switch (option)
20 Not assigned
