In this mode, the voice VLAN cannot be configured with a separate address but shares the IP

address of the VLAN interface of the device.

On the web interface, click Basic>VLAN, and ensure that the VLAN function is set to On, and Mode is

set to Multi-service VLAN. Select Mode 2 for Voice VLAN, and specify VLAN tags for SIP and

RTP/T.38.

Figure 3-7 Configuring Voice VLAN to Work in Mode 2

 

Configuring Management VLAN

The device adds VLAN tag configured in the management VLAN for HTTP, HTTPS and Telnet packets.

On the web interface, click Basic>VLAN, and ensure that the VLAN function is set to On and Mode is

set to Multi-service VLAN. Select Management VLAN, set the VLAN tag of the management service,

and specify network information such as IP address.
