MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 15
 Security strategy: IP filter, encryption
 Support PSTN failover through FXO ports
 Support G.711 fax pass-through and T.38 fax relay
 Support polarity inverse detection and busy tone detection
 3-way calling
 Compatible with unified communication solutions, such as Call Manager, Lync, Asterisk and Free
SWITCH
 Support SNMPv2 and TR069/TR104/TR106
 Support Web GUI-based management , SSH, automatic software upgrades, and configuration
downloading
 Support high availability, implementing a cloud of SIP servers working in primary-standby or load
balancing mode
 Support auto provisioning
 Support security settings such as accessing whitelists
 Message waiting indications (MWI) with high voltage, FSK, or reversed polarity
 Support accessing the Web GUI by using HTTPS
 Support Ping blocking
 Support optional voice interface cards (only supported by the MX8A/MX120G)
 Support the VPN client (only available with the HX4E/MX8A/HX4G/MX8G)
 Support VLAN
 Support New Rock Cloud, allowing New Rock devices located behind NAT or firewall to be easily
accessed.
1.3 Equipment Structure
1.3.1 HX4E/HX4G
The HX4E/HX4G adopts a compact plastic structural design and can be placed on a desk.
It provides either two or four FXS/FXO ports.
The HX4E/HX4G supports the following models.
Table 1-2 Configuration Combination of HX4E/HX4G
Models
Number of FXS Ports
Number of FXO Ports
HX402E/HX402G
2
0
HX420E/HX420G
0
2
HX422E/HX422G
2
2
HX440E/HX440G
0
4
HX404E/HX404G
4
0
