User Manual MX Series Voice Gateway

72 New Rock Technologies, Inc.

Figure 2-29 Certificate Configuration Interface

Step 1

Prepare the OpenVPN certificate file “client.vpn” based on the information provided by the

server. For details, see 4 Making an OpenVPN Client Certification.

Step 2

Click

Upload

Step 3

Select and upload the file client.ovpn.

Step 4

Reboot the device.

2.6.5 Media Stream

After login, click Advanced > Media Stream to open this interface.

Figure 2-30 HX4E/MX8A/HX4G/MX8G Media Stream Configuration Interface
