Indicator
Status
Description
Steady green
The device is running.
Off
The device is powered off or a power supply fault occurred
STU
(red, green)
Steady red
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
address failed to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing failed.
Blinking red
The device is starting or the KUPDATE is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration failed.
Blinking green
Calling.
Off
Registration has not started.
WAN
(green)
Steady green
A WAN connection is established without any service flow.
Blinking green
A WAN connection is established with service flow.
Off
WAN interface is disconnected.
PC
(green)
Steady green
A link is connected without any service flow.
Blinking green
A service flow is being transmitted.
Off
A link is not connected.
FXS/FXO
(green)
Steady green
Off-hook or call established
Blinking green
Ringing on incoming call
Off
The port is in idle status
1.3.2 MX8A/MX8G
The MX8A/MX8G adopts a compact metal structural design. It can be placed on a desk or installed in a
standard communications cabinet and provides eight analog ports. MX8A/MX8G supports the following
types of configuration.
Table 1-6 Configuration Combination of MX8A/MX8G
Models
Number of FXS Ports
Number of FXO Ports
MX8A-4S/4
MX8G-4S/4
4
4
MX8A-8S
MX8G-8S
8
0
MX8A-8FXO
MX8G-8FXO
0
8
