User Manual MX Series Voice Gateway
40 New Rock Technologies, Inc.
The gateway supports three registration schemes:
Per line (default): authenticate and register per line.
Per gateway: authenticate and register per gateway.
Per line/GW auth: Enable registration per line. Use the number configuration per line. Use the
global account and password in authentication.
Configure the user name as part of the account for registration. It has no default value.
Note: If Per gateway or Per line/GW Auth is selected for Registrar mode, the user name must be
entered here. If per line is selected the user name should be set on “Line> Feature” page (Refer to
2.3.2 Subscriber Line Features).
Password as part of account information is used for authentication by platform. It has no default
value. It can be formed with either numbers or characters, and is case sensitive.
Note: If Per gateway or Per Line/GW Auth is selected for Registrar mode, the password must be
entered here. If Per line is selected the password should be set on “Line>Feature” page (Refer to
2.3.2 Subscriber Line Features).
Valid time of SIP re-registration in seconds. Its default value is 600.
2.2.6 High Availability
After login, click Basic>SIP to open the configuration interface.
For details, see High Availability Configuration Guide.
Figure 2-8 High Availability Configuration Interface
Table 2-8 Parameters
High availability can be configured as Primary-Standby, Active-Standby or Load
Balancing mode.
Configure the address and port number of the backup SIP proxy server. When the
primary SIP server fails, the gateway failovers from the primary server to the backup
server automatically.
