Chapter 1: Product Introduction
VTC 7260 Series User Manual
ChaPter 1: ProduCt IntroduCtIon
Physical Features
VTC 7260-xC4 Front View
EXT. port is reserved for
optional I/Os function if needed.
VTC 7260-xC4 Rear View
Symbol “I” means Ignition that is connected to the car’s IGN.
To power up the machine, the Ignition (I) must be kept on
HIGH-level.
