Chapter 3: Jumpers and Connectors
VTC 7260 Series User Manual
VTC 7260-x/VTC 7260-xC4 Jumper/Switch/Expand slot on PCBA
This chapter describes the location and pinout assignment of the jumpers, slots, switched on VTC 7260 PCBA. The user can find out the slots
designed to be installed with the Wi-Fi modules, LTE/5G modules or Hailo AI card, etc.
Locations of the Jumpers and Connectors for the Motherboard
Top View
J1 (SATA PWR)
CN4 (SATA)
CN8
SW3
J5
J2 J3 J4
SW4
CN15
SW6
J7 (RTC batt.)
SW5
J10
J8 (COM3)
J9 (COM4)
CN17 (SIM2-1)
CN18 (SIM1-1)
