Chapter 2: External Connectors Pinout Description
VTC 7260 Series User Manual
HDMI Connector
Connector number: 13
Pin Definition Pin Definition
1 HDMI_TX2P 2 GND
3 HDMI_TX2N 4 HDMI_TX1P
5 GND 6 HDMI_TX1N
7 HDMI_TX0P 8 GND
9 HDMI_TX0N 10 HDMI_CLK_P
11 GND 12 HDMI_CLK_N
13 NC 14 NC
15 HDMI_SCL 16 HDMI_SDA
17 GND 18 HDMI_P5V
19 HDMI_HPD
19
18
2
1
VGA Connector
Connector number: 14
Pin Definition Pin Definition
1 VGA_RED 2 VGA_GREEN
3 VGA_BLUE 4 NC
5 GND 6 GND
7 GND 8 GND
9 +5V 10 GND
11 NC 12 VGA_DATA
13 VGA_HS 14 VGA_VS
15 VGA_CLK
5 1
15 11
15
1115
