Internal Connectors
CAN Terminator Resistor Selection Switch
Connector location: CN22/CN25
C1
C2
C3
C4
C5
C6
C7
C8
Pin Definition Pin Definition
C1 UIMA POWER C2 UIMB RESET
C3 UIMA CLK C4 N.C
C5 GND C6 N.C
C7 UIMA DATA C8 N.C
CD SIMA_DET
