Appendix H: Power Consumption
VTC 7260 Series User Manual
aPPendIx h: Power ConsumPtIon
OS: Windows 10
Burn-in Software:
Test Condition: Room temperature
Test Procedure: Idle, Full, Full+load and IGN OFF
Device: VTC 7260
Idle: Into OS + Display x2 + keyboard & mouse + audio + Audio + All Storage (Storage x1 Total 7w + mSATA)
Full State: Idle State, Module (RM500Q + AX210), Mini Card Dummy Load (4.36w+3.3w), Burn In 100%
(CPU+2D+3D+Disk+Sound+RAM+Video Playback+GPU), play video, COM trans (COM1+COM2), GPS link
Full State + Loading: Full state + USB Load: USB 3.0 (5V/1Ax3) / USB 2.0 (5V/1Ax1) + PoE (60W)
Item Device Test Case
Result
Average Maximum
Current(A) Watt(W) Current(A) Watt(W)
1
S0 State
Core i7-
1185GRE
(2.8GHz)
28W
Idle state
12V 1.56 18.72 3.02 36.24
24V 0.79 18.96 1.47 35.28
36V 0.54 19.44 1.04 37.44
Full-run state (Burn-In)
12V 3.02 36.24 3.21 38.52
24V 1.48 35.52 1.59 38.16
36V 1.03 37.08 1.11 39.96
Full-run state + loading
12V 4.36 52.32 4.55 54.6
24V 2.17 52.08 2.27 54.48
36V 1.53 55.08 1.62 58.32
Full-run state + loading (PoE w/ 60W)
12V 10.67 128.04 11.1 133.2
24V 4.82 115.68 4.95 118.8
