Appendix E: Signal Connection of DI/DO
VTC 7260 Series User Manual
aPPendIx e: sIGnal ConneCtIon of dI/do
GPIO Pinout Description
Pin Definition Pin Definition
1 2
3 GPO3 4 GPI1
5 GPO0 6
7 8
9 GPI2 10 GPO1
11 12
13 GPI3 14 GPO2
15 GPI0
5
15
1
11
