Chapter 3: Jumpers and Connectors
VTC 7260 Series User Manual
Pin Definition Pin Definition
1 GND 2 1PPS
3 ODOMETER 4 DIRECTION
GPS DR Connector
Connector type: 1x4 4-pin header
Connector location: J4
14
Pin Definition Pin Definition
1 GND 2 USB2_DP
3 USB2_DN 4 USB_5V
Internal USB2.0 Connector
Connector type: 1x4 4-pin header
Connector location: J5/J11
14
