Appendix G: TPM Setup (Optional)
VTC 7260 Series User Manual
aPPendIx G: tPm setuP
BIOS Screen with TPM Module BIOS Screen with No TPM Module
Advanced
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enables or Disables BIOS
support for security device.
O.S. will not show Security
Device. TCG EFI protocol and
INT1A interface will not be
available.
TPM20 Device Found
Conguration
Security Device Support
Active PCR banks
Available PCR banks
SHA-1 PCR Bank
SHA256 PCR Bank
Pending operation
Platform Hierarchy
Storage Hierarchy
Endorsement Hierarchy
[Enable]
SHA-1
SHA-1,SHA256
[Enabled]
[Disabled]
[None]
[Enabled]
[Enabled]
[Enabled]
Advanced
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enables or Disables BIOS
support for security device.
O.S. will not show Security
Device. TCG EFI protocol and
INT1A interface will not be
available.
Conguration
Security Device Support
NO Security Device Found
[Enable]
When TPM module is mounted on
ATC 8110, you will see the message:
TPM20 Device Found and TPM activated
When no TPM module is mounted on
ATC 8110, you will see the message:
NO Security Device Found
The default factory setting
when TPM is enabled
The user can select SHA-1 or SHA256 as the
encryption method used by the TPM module
