Appendix H: Power Consumption
VTC 7260 Series User Manual
Item Device Test Case
Result
Average Maximum
Current(A) Watt(W) Current(A) Watt(W)
2
S0 State
Core i3-
115GRE
28W
Idle state
12V 1.52 18.24 3.21 38.52
24V 0.85 20.4 1.75 42
36V 0.7 25.2 1.28 46.08
Full-run state (Burn-In)
12V 3.25 39 3.82 45.84
24V 1.74 41.76 2.09 50.16
36V 1.32 47.52 1.52 54.72
Full-run state + loading
12V 4.41 52.92 4.93 59.16
24V 2.33 55.92 2.52 60.48
36V 1.71 61.56 1.88 67.68
Full-run state + loading (PoE w/ 60W)
12V 9.95 119.4 10.45 125.4
24V 4.77 114.48 5.08 121.92
36V 3.21 115.56 3.37 121.32
3 S3 State Full state Sleep mode
12V 0.23 2.75 N/A N/A
12V wake up
WWAN
0.23 2.76 N/A N/A
4 IGN OFF
Full state
IGNITION OFF
12V 0.009 0.108 N/A N/A
12V wake up
WWAN
0.055 0.66 N/A N/A
24V 0.008 0.192 N/A N/A
24V wake up
WWAN 0.035 0.84 N/A N/A
36V 0.008 0.288 N/A N/A
36V wake up
WWAN 0.028 1.008 N/A N/A
