Chapter 1: Product Introduction
VTC 7260 Series User Manual
Display
▪ 1 x HDMI 2.0a/b, up to 3840 x 2160@60Hz
▪ 1 x VGA, up to 2560 x 1600@60Hz
▪ 1 x DP, 4096 x 2304@60Hz
2.5GbE
▪ 2-port independent 2.5GbE, RJ45 connector
- 9K byte jumbo frame
- PTP (IEEE 1588) support
- Controller: Intel
®
I225-IT
GbE
▪ 1-port independent GbE, RJ45 connector
- vPro (iAMT) support
- 9K byte jumbo frame
- PTP (IEEE 1588) support
- Wake-up function (WoL)
- Boot from PXE (Legacy & UEFI)
USB
▪ 1 x USB 3.2 Gen2 & 2 x USB 3.2 Gen1:
- Host type-A connector
- 5V@900mA each
- Up to 10Gbit/s link speed & compliance with USB 2.0 (LS/FS/HS link
speed)
▪ 1 x USB 2.0, host type-A connector
Serial Port
▪ 2 x full RS232/422/485, selectable
▪ 2 x full RS232 reserved for option (wafer connector)
- RS232 working voltage, +- 9V, baud rate up to 115.2kb/s
Security
▪ TPM 2.0: Infineon SLB9665TT2.0FW5.62
Audio
▪ Line-out, unbalance stereo, left & right channel
▪ MIC-in, stereo
▪ Line-in reserved (wafer connector)
MEMS Sensor
▪ 3D accelerometer and 3D gyroscope
▪ Controller: ST LSM6DSLTR
DI/DO
▪ 4-bit input
- Source: 9~36VDC (12V@1.1mA/24V@2.2mA)
- External: 0~33VDC pull-high, high-level, 3.3 - 33 VDC; low-level, 0 - 2
VDC
▪ 4-bit output
- Source: 9~36VDC (nominal 35mA@24V):
- External: 5~27VDC pull-high, sink current w/ 220mA for each bit,
500mA max (@25C)
▪ Source or external can be selected by DIP switch (default: source type)
