Appendix C: GPS Feature
VTC 7260 Series User Manual
Tracking features
Power save modes On/off, cyclic
Data batching Autonomous tracking up to 5 minutes
Data-logger Position, velocity, time, and odometer date
Geofencing Up to 5 circular areas;
Sofware message or GPIO for waking up the host
CPU
Security features
Signal integrity RF interference & jamming detection and reporting
Active GNSS in-band filtering
Spoofing detection and reporting
Device integrity Secure boot of firmware downloaded from host or
flash
Receiver configuration lock by command
Secure interference Signed UBX messages (SHA-256)
JTAG port locked
Electrical data
Power supply 2.7V to 3.6V
Power
Consumption
1
36 mA at 3.0 V (4 GNSS continuous)
32 mA at 3.0 V (2 GNSS continuous)
28 mA at 3.0 V (1 GNSS continuous)
Backup Supply 1.65 V to 3.6 V
Package
24 pin LCC (Leadless Chip Carrier): 12.2 x 16.0 x 2.4 mm, 1.6 g
Environmental data, quality & reliability
Operating temp. -40°C to +85°C
Storage temp. -40°C to +85°C
Environmental grade 2015/863/EU RoHS-3
EMC 2014/53/EU RED
Environmental
testing
ISO 16750
Quality
management
Manufactured and fully tested in IATF 16949
certified production sites
Interfaces
Signal integrity 1 UART
1 USB (NEO-M9N)
1 SPI (optional)
1 DDC (I2C compliant)
Digital I/O Configurable timepulse
1 EXTINT input for Wakeup
Raw Data output Code phase date
Timepulse Configurable: 0.25 Hz to 10 MHz
Supported
antennas
Active and passive
Protocols NMEA 4.10, UBX binary, RTCM 3.3
Services
Assistance GNSS AssistNow Online
AssistNow Offline (up to 35 days)
AssistNow Autonomous (up to 6 days)
OMA SUPL & 3GPP compliant
