Doc# E107706 9- 14
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
9: External I/O Modules
9.8: Digital Solid State Pulse Output (KYZ) Module
9.8.1: Overview
The KYZ Pulse Output Modules have 4 KYZ Pulse Outputs and accept Read and Write
Commands with at least 4 registers of data per command. Digital Solid State Pulse
Output (KYZ) Modules are user programmed to reflect VAR-hours, Watt-hours, or
VA-hours. See the Modbus Communicating I/O Modules User Manual for details on
programming the module.
The Nexus® 1250/1252 meter supplies power for up to 4 connected KYZ Pulse Output
modules. See Section 9.2 for power and communication details. Refer to Section 5.6.2
to determine if you must use an additional power source, such as EIG’s PSIO.
Digital Solid State Pulse Output Module Specifications
Model Number 4PO1
Communication RS485, Modbus RTU
Programmable Baud Rates: 4800, 9600, 19200,
38400, 57600
Power Requirement 12-20VDC @50-200mA; 1250/1252 supports up to
four modules
Operating Temperature
(-20 to +70)
o
C/(-4 to +158)
o
F
Voltage Rating Up to 300VDC
Commands Accepted Read and Write with at least 4 registers of data per
command
Memory 256 Byte IC EEPROM for storage of programmable set-
tings and non-volatile memory
Factory Settings Modbus Address: 160
Baud Rate: 57600
Transmit Delay Time: 0
Default Settings (Reset Button) Modbus Address: 247
Baud Rate: 57600
Transmit Delay Time: 20msec
