Doc# E107706 2 - 18
2: Meter Overview
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
* EN50160/EN61000-4-30 PQ Analysis is only available for a Nexus® 1252 meter
with V- Switch™ key 2.
2.10: Nexus
®
P40N+, P41N+, P43N+ LED External Display
Specifications
Update Time 200msec - High-speed readings
1 sec - Revenue-accurate reading
Frequency Range Fundamental 20-65Hz
Up to 255th Harmonic Measuring
Capability
Dimensions (HxWxL) 3.4 x 7.3 x 10.5 in/8.6 x 18.5 x 26.6 cm
Maximum Power Consumption 40 Watts (with optional modules and
display)
Nominal Power Consumption Approximately 12 Watts (without
optional modules or display)
Operating Temperature
(-40 to +70)
o
C/(-40 to +158)
o
F
Auxiliary Output Power Voltage 15-20VDC at 5-200mA
Maximum Auxiliary Power Current 1A (short protected)
Maximum Power Supply Range (100-250)VAC
UL Listing 61010-1 (
not evaluated for accuracy,
reliability, or capability to perform intended
function
)
Flicker (Nexus
®
1252)
Evaluation per IEC 61000-4-15
EN50160/IEC 61000-4-30 PQ Analysis Evaluation per IEC 61000-4-30*
IRIG-B Port Impedance 8mA@5V
Specification P40N+/P41N+/P43N+ Displays
Maximum Input Voltage 30VDC
Minimum Input Voltage 12VDC
Maximum Power Consumption 5W
Nominal Power Consumption Approximately 3W
Operating Temperature Range
(-20 to +70)
o
C/(-4 to +158)
o
F
Overall Dimensions (HxWxD) *5.25 x 5.25 x1.79 inches/13.34 x 13.34 x
4.54 cm
Specification
Nexus
®
meter
