13: Substation Rack Mount Assembly
Figure 13.3: Back of Rack Assembly
Figure 13.4: Detail of Test Switches
Test
Switch
Displays connected to
meter’s
Port 3
Port 1 Serial Connection
going to front of the unit
POT
AØ
CURRENT
AØ
POT
BØ
CURRENT
BØ
POT
CØ
CURRENT
CØ
POT
N
DC SUPPLY
+ –
1 2 3 4 5 6 7 8 9 10 11 12
Low High Low High Low High
