Nexus 1250 - Page 56

Doc# E107706 3 - 6
3: Hardware Installation
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Figure 3.6: I/O Module Communication Ports and Mounting Brackets
Figure 3.7: I/O Modules Mounting Diagram Front View
Mounting Brackets (MBIO)
Male RS485
Side Port
Female RS485
Side Port
I/O Port
(Size and Pin
Configuration Vary)

$!.'%2
/N
,
0OWER3UPPLY
03)/
-AX0OWER6!
)NPUT6OLTAGE6$#
WWWELECTROINDCOM
/UTPUT6OLTAGE6$#
%LECTRO)NDUSTRIES'AUGE4ECH
6!#$#
.
0OWER)N
Mounting Bracket
6.879”/13.088cm
1.100”/2.54cm
1.301”/3.305cm
.618”/1.570cm
2.200”/5.588cm
3.437”/8.729cm
Mounting Bracket
