National Instruments Corporation
Configure and Install Your AT-GPIB/TNT
Previous
Step
12
6. Insert the AT-GPIB/TNT into the slot with the GPIB connector sticking out of the opening on
the back panel, as shown in Figure 3. It might be a tight fit, but do not force the board into
place.
Figure 3. Installing the AT-GPIB/TNT
7. Screw the mounting bracket of the AT-GPIB/TNT to the back panel rail of the computer.
8. Replace the top cover (or the access panel to the expansion slot).
9. Power on your computer and start Windows.
The AT-GPIB/TNT hardware installation is now complete.
